100-600mm Punching Plc Cable Tray Roll Forming Machine

Name: 100600mm Punching Plc Cable Tray Roll Forming Machine
Brand: LIMING
Price: 1 USD

Brand Name : LIMING

Model Number : LM-Bridge 5.1

Certification : CE、BV、ISO

Place of Origin : China

MOQ : 1

Price : Negotiation

Payment Terms : T/T, L/C, D/A, D/P, T/T, Western Union, MoneyGram, Western Union

Supply Ability : 450set/Year

Delivery Time : 45 work days

Packaging Details : Nude、Anti-dust film, Anti-rust cloth

Showroom Location : Pakistan, India, Russia

Rolling thinckness : 0.3-1.0mm

Dimension(L*W*H) : 7500*1700*1600Mm

Warranty : 1.5 years

Voltage : 380v 50Hz

Core Components : Motor, Pump, PLC

Weight : 10T

Contact Now

Size-adjustable cable tray punching forming machine has good sales in the industry

We are a cable tray punching machine manufacturer. Our company has a professional design, manufacturing, sales, and after-sales team that can help customers solve all problems about cable tray punching machines. At the same time, our company also produces cable tray products. Meet the needs of customers using cable tray products. If you need to produce cable tray forming machine, we can provide it for you.

Technical parameters of Size-adjustable cable tray punching forming machine has good sales in the industry

Name	cable tray making machine
Decoiler	Electric feeding, hydraulic tightening
Roller material	GR15 steel
Coil ID	φ508mm/φ610mm
Control system	PLC System
Hydraulic system power	3kw Shaft diameter: φ190mm Tighten cylinder diameter: φ200mm
Hydraulic system oil pump	vane pump Hydraulic system solenoid valve brand: Beijing huade
Cutting blade material	Cr12Mov steel

The cable tray forming machine is divided into uncoiling module-punching module-rolling small side module-large side bending module-splicing module. The whole machine is controlled by the PLC electronic control system, and only one person can complete the entire production. Process, which can help you save a lot of labor costs.

The cable tray forming machine is also equipped with an adjustable punching device, so that the hole distance of the cable tray can be adjusted at will to meet the purpose of easy installation of cable tray products.

The width of 100-600 does not need to be customized production, because our cable tray forming machine has a width of 100-600 that can be adjusted at will to meet your needs for multiple specifications of cable trays.

100-600mm Punching Plc Cable Tray Roll Forming Machine
