Durable Light Steel Frame Villa Keel Forming Machine

Name: Durable Light Steel Frame Villa Keel Forming Machine
Brand: LIMING
Price: 1 USD

Brand Name : LIMING

Model Number : LM-lLGS3

Certification : CE、BV、ISO

Place of Origin : China

MOQ : 1

Price : Negotiation

Payment Terms : T/T, L/C, D/A, D/P

Supply Ability : 450set/Year

Delivery Time : 30 work days

Packaging Details : Nude、Anti-dust film, Anti-rust cloth

Applicable Industries : Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops

Work Pressure : 120 MPA---140 MPA

After-sales Service Provided : Online support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Video technical support

Warranty : 2 Years

Voltage : 380V/50HZ 3Phase

Shaft material : 40Cr

Speed : 10-12/min

Profile Dimension(Web*Flange*Lip) : 89mm*38mm*9mm

Contact Now

Durable Light Steel Frame Villa Keel Forming Machine

The durable light steel frame villa keel forming machine is a new product launched by our company in 2020

The durable light steel frame villa keel forming machine is the first to efficiently and stably produce double roll paper C89/C91.

The durable light steel frame villa keel forming machine realizes time-saving assembly, convenient management, and fast assembly speed.

The assembly efficiency of the durable light steel frame villa keel forming machine is increased by 50%

Technical parameters of Durable Light Steel Frame Villa Keel Forming Machine

No.	Durable light steel frame villa keel forming machine
1	Suitable material	PPGI/Aluminium sheet/galvanized sheet/various sheet plates
2	Thickness of coil sheet	0.2-0.6mm
3	Coil width	as customer's profile drawing requirement
4	Effective width	as customer's profile drawing requirement
5	Material of main frame	welded by 600mm steel plate
6	Diameter of Soild shaft	40mm, high grade 45# steel
7	Roller	Cr12, quenched and tempered treatment,
7	Roller	hard chrome plated 0.05-0.07mm
8	Thickness of middle plate	Memorial archway
9	Forming station	12 rows
10	Drive type	Gear
11	Power of main motor	4.0 kw Shanghai, with reducer
12	Servo motor	1.5KW
13	Forming speed	About 0-25m/min
14	Hydraulic pump station	5.5 kw, 40# hydraulic oil
15	PLC	Delta(TaiWan)
16	Material of razor blades	Cr 12, quenching 58-62℃
17	Frequency converter	It has the advantage of slowing down before cutting, to ensure the
17	Frequency converter	length accuracy ±1mm, far better than industrial standard ±3mm.
18	Switch	CHNT
19	Frequency changer	SAJ

Quality Durable Light Steel Frame Villa Keel Forming Machine for sale

Durable Light Steel Frame Villa Keel Forming Machine Images
